Dimensions:
Depth: 10mm Wjdth: 85 mm
Weight: 0.11Kg Length: 194 mm.
Technical:
Material: Steel 0.9mm thick
Hole size: 4 x 6mm
Extra Information:
Plates are, manufactured in plastic coated steel with folded
edges to give additional strength. Coating is 200 microns thick, with an impact
strength of 18J, maximum surface temperature
60'c. Fire classification class1
flame resistant surface as Swedish standard SS 02 48 23 class
1 surface as
per BS476 Part 7 and Baustoff klasse B2 as per DIN 4102 Teil1 UV resistance.
Colour:Ocean blue
Compliance. BS476 part 7
